Midea Display Board Subassembly Part# 17220600002201

Weight: 2 lbs. Dimensions: Not Available

Compatible Models: MAP05R1WWT, CP05S3WBA1RCM, MP05SRWBA3RCM, KSTAP05PHA, MAP05R1WT, SM09R1, MAP06R1BWT, 0653833218, 4307498, VP05DMWBA2RCM, MAP08R1CWT, VAP09R1AWT, MP05DRWBA3RCM

Existing reviews

Repair Note

Connector alignment matched better than expected while replacing the old component because the control panel stopped responding randomly. Everything powered back on correctly afterward.

From: Guest | Date: 6/30/2025 9:36 AM

Was this review helpful? Yes No (0/0)

Helpful Product Insight

Installed this when the buttons were no longer reacting correctly. Mounting holes lined up correctly during install. Appliance has been running normally since then.

From: Guest | Date: 8/31/2025 9:36 AM

Was this review helpful? Yes No (0/0)

Installation Experience

Ended up ordering this because the refrigerator would reboot intermittently. Had to double check model compatibility first. No leaks or issues noticed so far. Worth verifying model number before ordering though.

From: Peter | Date: 3/28/2026 9:36 AM

Was this review helpful? Yes No (0/0)

Only registered users can write reviews
